Urban Lightning
Pole
CD LED EVO-4
CD LED EVO-4

CD LED EVO-4

Warranty
Protection from external agents
Impact protection
Pre-wired
RG
Cut-Off
Dimming
Anthracite RAL 7016 Corten

Street furniture luminaire for installation on Ø60 mm poles at the top. Upper part in die-cast aluminium, anodised and powder coated, with specific pre-treatment for outdoor use. Diffuser in flat tempered glass with high transmittance and screen-printed, 5 mm thick. Base in reinforced technopolymer and pre-connected cable, fixed by cable gland with built-in osmotic valve.


CD LED EVO-4
Color Version Size Power Power supply Luminaire Output Light source Dimmable driver Packing Insulation class Cod
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K DALI 1 II 250-126817DJ
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K DALI 1 II 250-126817DS
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K DALI 1 II 250-126817FJ
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K DALI 1 II 250-126817FS
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K   1 II 250-1268182J
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K   1 II 250-1268182S
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K   1 II 250-1268184J
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K   1 II 250-1268184S
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K DALI 1 II 250-126827DJ
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K DALI 1 II 250-126827DS
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K DALI 1 II 250-126827FJ
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K DALI 1 II 250-126827FS
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K   1 II 250-1268282J
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K   1 II 250-1268282S
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K   1 II 250-1268284J
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K   1 II 250-1268284S
Corten 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K DALI 1 II 250-126837DJ
Anthracite RAL 7016 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K DALI 1 II 250-126837DS
Corten 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K DALI 1 II 250-126837FJ
Anthracite RAL 7016 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K DALI 1 II 250-126837FS
Corten 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K   1 II 250-1268382J
Anthracite RAL 7016 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K   1 II 250-1268382S
Corten 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K   1 II 250-1268384J
Anthracite RAL 7016 180° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K   1 II 250-1268384S
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K DALI 1 II 250-126917DJ
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K DALI 1 II 250-126917DS
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K DALI 1 II 250-126917FJ
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K DALI 1 II 250-126917FS
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K   1 II 250-1269182J
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3100 lm Led 4000 K   1 II 250-1269182S
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K   1 II 250-1269184J
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 2947 lm Led 3000 K   1 II 250-1269184S
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K DALI 1 II 250-126927DJ
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K DALI 1 II 250-126927DS
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K DALI 1 II 250-126927FJ
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K DALI 1 II 250-126927FS
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K   1 II 250-1269282J
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4490 lm Led 4000 K   1 II 250-1269282S
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K   1 II 250-1269284J
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4268 lm Led 3000 K   1 II 250-1269284S
Corten 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K DALI 1 II 250-126937DJ
Anthracite RAL 7016 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K DALI 1 II 250-126937DS
Corten 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K DALI 1 II 250-126937FJ
Anthracite RAL 7016 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K DALI 1 II 250-126937FS
Corten 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K   1 II 250-1269382J
Anthracite RAL 7016 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5917 lm Led 4000 K   1 II 250-1269382S
Corten 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K   1 II 250-1269384J
Anthracite RAL 7016 360° ⌀400x125 mm 50 W 200-240V 50/60Hz 5624 lm Led 3000 K   1 II 250-1269384S
