Urban Lightning
Pole
CD LED EVO-3
CD LED EVO-3

CD LED EVO-3

Warranty
Protection from external agents
Impact protection
Pre-wired
RG
Cut-Off
Dimming
Anthracite RAL 7016 Corten

Street furniture luminaire for installation on Ø60 mm poles at the top. Upper part in die-cast aluminium, anodised and powder coated, with specific pre-treatment for outdoor use. Diffuser in flat tempered glass with high transmittance and screen-printed, 5 mm thick. Base in reinforced technopolymer and pre-connected cable, fixed by cable gland with built-in osmotic valve.


CD LED EVO-3
Color Version Size Power Power supply Luminaire Output Light source Dimmable driver Packing Insulation class Cod
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K DALI 1 II 250-116817DJ
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K DALI 1 II 250-116817DS
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K DALI 1 II 250-116817FJ
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K DALI 1 II 250-116817FS
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K   1 II 250-1168182J
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K   1 II 250-1168182S
Corten 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K   1 II 250-1168184J
Anthracite RAL 7016 180° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K   1 II 250-1168184S
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K DALI 1 II 250-116827DJ
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K DALI 1 II 250-116827DS
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K DALI 1 II 250-116827FJ
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K DALI 1 II 250-116827FS
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K   1 II 250-1168282J
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K   1 II 250-1168282S
Corten 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K   1 II 250-1168284J
Anthracite RAL 7016 180° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K   1 II 250-1168284S
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K DALI 1 II 250-116917DJ
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K DALI 1 II 250-116917DS
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K DALI 1 II 250-116917FJ
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K DALI 1 II 250-116917FS
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K   1 II 250-1169182J
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3195 lm Led 4000 K   1 II 250-1169182S
Corten 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K   1 II 250-1169184J
Anthracite RAL 7016 360° ⌀400x125 mm 25 W 200-240V 50/60Hz 3038 lm Led 3000 K   1 II 250-1169184S
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K DALI 1 II 250-116927DJ
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K DALI 1 II 250-116927DS
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K DALI 1 II 250-116927FJ
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K DALI 1 II 250-116927FS
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K   1 II 250-1169282J
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4438 lm Led 4000 K   1 II 250-1169282S
Corten 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K   1 II 250-1169284J
Anthracite RAL 7016 360° ⌀400x125 mm 37 W 200-240V 50/60Hz 4218 lm Led 3000 K   1 II 250-1169284S
