Residenziale
Parete
DELUX UP

DELUX UP

Protezione da agenti esterni
Protezione da urti
Rischio fotobiologico
WI-FI on/off
WI-FI dimm
Antracite RAL 7016 Corten Grigio RAL 9006 Bianco RAL 9016

Apparecchio d’arredo urbano per installazione a parete o su pali dedicati. Realizzato  in  alluminio  estruso  anodizzato  e  verniciato  a  polvere,  con pretrattamento  specifico  per  esterni.  Lente  in  PMMA  trasparente, inalterabile  ai  raggi  UV con possibilità di installare ottiche particolari su richiesta.  Staffa  per  fissaggio  a  parete  in  acciaio  inox. Pali  dedicati  a  sezione  quadrata,  da  interro  o  flangiati con o senza morsettiera,  da ordinare separatamente. Possibilità di controllo remoto con Wi-Fi.

DELUX UP
DELUX UP
Colore Dimensioni Ottiche Potenza Alimentazione Output apparecchio Sorgente luminosa Dimmable driver Confezione Classe isolamento Cod
Bianco RAL 9016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K DALI 1 II 100-122117DB
Corten 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K DALI 1 II 100-122117DJ
Grigio RAL 9006 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K DALI 1 II 100-122117DM
Antracite RAL 7016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K DALI 1 II 100-122117DS
Bianco RAL 9016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K DALI 1 II 100-122117FB
Corten 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K DALI 1 II 100-122117FJ
Grigio RAL 9006 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K DALI 1 II 100-122117FM
Antracite RAL 7016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K DALI 1 II 100-122117FS
Bianco RAL 9016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K   1 II 100-1221182B
Corten 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K   1 II 100-1221182J
Grigio RAL 9006 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K   1 II 100-1221182M
Antracite RAL 7016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K   1 II 100-1221182S
Bianco RAL 9016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K   1 II 100-1221184B
Corten 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K   1 II 100-1221184J
Grigio RAL 9006 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K   1 II 100-1221184M
Antracite RAL 7016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K   1 II 100-1221184S
Bianco RAL 9016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119GB
Corten 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119GJ
Grigio RAL 9006 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119GM
Antracite RAL 7016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1215 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119GS
Bianco RAL 9016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119HB
Corten 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119HJ
Grigio RAL 9006 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119HM
Antracite RAL 7016 250x85x85 mm Stradale Short 10 W 220-240V 50-60Hz 176-240Vdc 1080 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122119HS
Bianco RAL 9016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K DALI 1 II 100-122217DB
Corten 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K DALI 1 II 100-122217DJ
Grigio RAL 9006 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K DALI 1 II 100-122217DM
Antracite RAL 7016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K DALI 1 II 100-122217DS
Bianco RAL 9016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K DALI 1 II 100-122217FB
Corten 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K DALI 1 II 100-122217FJ
Grigio RAL 9006 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K DALI 1 II 100-122217FM
Antracite RAL 7016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K DALI 1 II 100-122217FS
Bianco RAL 9016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K   1 II 100-1222182B
Corten 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K   1 II 100-1222182J
Grigio RAL 9006 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K   1 II 100-1222182M
Antracite RAL 7016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K   1 II 100-1222182S
Bianco RAL 9016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K   1 II 100-1222184B
Corten 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K   1 II 100-1222184J
Grigio RAL 9006 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K   1 II 100-1222184M
Antracite RAL 7016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K   1 II 100-1222184S
Bianco RAL 9016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219GB
Corten 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219GJ
Grigio RAL 9006 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219GM
Antracite RAL 7016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2250 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219GS
Bianco RAL 9016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219HB
Corten 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219HJ
Grigio RAL 9006 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219HM
Antracite RAL 7016 300x85x85 mm Stradale Short 19 W 220-240V 50-60Hz 176-240Vdc 2160 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122219HS
Bianco RAL 9016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K DALI 1 II 100-122317DB
Corten 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K DALI 1 II 100-122317DJ
Grigio RAL 9006 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K DALI 1 II 100-122317DM
Antracite RAL 7016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K DALI 1 II 100-122317DS
Bianco RAL 9016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K DALI 1 II 100-122317FB
Corten 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K DALI 1 II 100-122317FJ
Grigio RAL 9006 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K DALI 1 II 100-122317FM
Antracite RAL 7016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K DALI 1 II 100-122317FS
Bianco RAL 9016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K   1 II 100-1223182B
Corten 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K   1 II 100-1223182J
Grigio RAL 9006 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K   1 II 100-1223182M
Antracite RAL 7016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K   1 II 100-1223182S
Bianco RAL 9016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K   1 II 100-1223184B
Corten 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K   1 II 100-1223184J
Grigio RAL 9006 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K   1 II 100-1223184M
Antracite RAL 7016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K   1 II 100-1223184S
Bianco RAL 9016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319GB
Corten 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319GJ
Grigio RAL 9006 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319GM
Antracite RAL 7016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3880 lm Led 4000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319GS
Bianco RAL 9016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319HB
Corten 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319HJ
Grigio RAL 9006 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319HM
Antracite RAL 7016 400x85x85 mm Stradale Short 27 W 220-240V 50-60Hz 176-240Vdc 3688 lm Led 3000 K Wi-Fi (ON/OFF - DIMM) 1 II 100-122319HS
DELUX UP
DELUX UP

    Abbinamenti

      Accessori

        Similari

          Download

          UE-DELUX UP-ENG.PDF

          UE-DELUX UP-ITA.PDF

          100-1221182S.LDT

          100-1221184S.LDT

          100-1222182S.LDT

          100-1222184S.LDT

          100-1223182S.LDT

          100-1223184S.LDT
